Application:

1. Widely used for emergency lighting during power outages in hazardous environments such as oil extraction, petroleum refining, chemical processing, and military industries;

2. Suitable for locations requiring high levels of protection or environments with high humidity;

3. Suitable for Zone 1 and Zone 2 explosive gas environments;

4. Suitable for Class IIA, IIB, and IIC explosive gas environments;

5. Suitable for Zone 21 and Zone 22 combustible dust environments;

6. Suitable for temperature classes T1 through T6;

Features:

1. Die-cast aluminum alloy housing with a high-pressure electrostatic powder-coated finish;

2. Tempered glass lens and stainless steel external fasteners;

3. Dedicated emergency-only design with LED light source; operates only during emergencies;

4. Compatible with both steel conduit and cable wiring methods;

Controller Features:

1. Built-in maintenance-free battery pack; charges automatically during normal power supply and activates immediately upon power failure or outage;

2. Automatic switching to emergency mode; includes protection against over-discharge and over-charge;

3. Monthly inspection function: automatic discharge once a month, maintaining emergency operation for 120 seconds before automatically reverting to mains power;

4. Annual inspection function: automatic switch from mains power to emergency mode once a year, continuing until discharge is complete, followed by automatic reversion to mains power;

Parameters:

1. Rated Voltage: AC 220V, 50Hz (DC 24V/36V available upon request)

2. Emergency Lighting: LED light source (2 x 3W or 2 x 1.5W)

3. Charging Time: 24 hours

4. Discharge Time: 120 minutes

5. Explosion-proof Marking: Exde mb IIBT6 GB

6. Ingress protection rating: IP65

7. Corrosion protection rating: WF1

8. Cable entry: G3/4"

9. Terminal block: 2.5 mm²

10. Mounting method: Wall-mounted

11. Luminaire weight: 2.3 kg

Tags: Explosion Proof Emergency Exit Lights
