APPLICATIONS
Suitable for fixed lighting in various indoor and outdoor workplaces, including those in China's coal industry, PetroChina, Sinopec, CNOOC, power, metallurgy, railway, steel, shipbuilding, military, public security and fire protection, chemical industry, government departments, and large enterprises.

FEATURES
1. Employs a high-efficiency, high-frequency electrodeless lamp source, and through advanced light distribution design and special processing, provides soft, uniform, and glare-free light with an average lifespan exceeding 50,000 hours.
2. Utilizes a high-strength aluminum alloy shell and optimized structural design, offering resistance to strong impacts and shocks.
3. High-tech surface coating technology achieves an IP65 protection rating, ensuring the lamp will not corrode or rust in harsh environments.
4. Two light distribution designs are available: a symmetrical design and an asymmetrical design, allowing selection based on different on-site lighting needs.
5. Independent cavity structure design ensures excellent heat dissipation, significantly extending the lamp's lifespan; maintenance is convenient and simple. The compact structure, aesthetically pleasing appearance, and easy installation are supported by various mounting methods, including recessed and ceiling-mounted installations.

Wiring method
A. Disconnect power supply, then open light fitting.
B. Strip cable jacket with appropriate length (40mm). Remove gland nut cover and rubber filling, pull the cable through the cover, rubber filling and gland nut, and fasten the cover to gland nut tightly.
C. Undo screws on the wiring holder by a flat screwdriver. Connect neutral wire to No.2 hole, live wire to No. 3 hole, earthing wire to No. 1 hole, and tighten screws by the screwdriver.
D. Re-install the cover and tighten it.
E. Connect power supply.
