APPLICATIONS
1、 Ideal for illumination of outdoor opera-tions in various industries.
2、Suitable for illumination of construction works, repair works, emergency rescues, relief works, etc.

FEATURES
1、1000W lamps providing high efficiency and luminance
2、Maximum height up to 4.5m or 3.5m
3、Radius of illumination area up to 30m-50m
4、Fitted with a remote controller to control the tower within 30m
5、Fitted with casters and rail wheels on the base
6、Wind stability up to Scale 8

TECHNICAL DATA
Body material：Aluminum alloy
Diffuser：Tempered glass
Rated voltage：220V / 230 V / 240 V AC
Operating voltage：220V / 230 V / 240 V AC
Wattage：1000 W
Type：Halogen
Luminous flux：7500 lm
Life：2000 h
Mains supply：Continuous
                        ER2500CX  generating set：13 h(after filled up)
                        EG6500CX generating set：12 h(after filled up)
Min. height：1800 mm
Max. height：3500 mm / 4500 mm / 5700 mm
Lifting time：30 s
Rated output voltage：220 V AC
Rated output power：2000 W( ER2500CX )
                                  5000 W( EG6500CX )
Rated capacity of fuel tank：15 L
Degree of protection：IP65
Ambient temperature：-20 ºC to +55 ºC
Light fittings：7.0 kg
Telescopic mast：8.0 kg
KD6500E generating set：95.0 kg
