APPLICATIONS

1、 Ideal for illumination of outdoor opera-tions in various industries.

2、Suitable for illumination of construction works, repair works, emergency rescues, relief works, etc.

FEATURES

1、4×500W lamps providing high efficiency and luminance

2、Maximum height up to 4.5m or 3.5m

3、Radius of illumination area up to 30m-50m

4、Fitted with a remote controller to control the tower within 30m

5、Fitted with casters and rail wheels on the base

6、Wind stability up to Scale 8

TECHNICAL DATA

Body material：Aluminum alloy

Diffuser：Tempered glass

Rated voltage：220V / 230 V / 240 V AC

Operating voltage：220V / 230 V / 240 V AC

Wattage：4 × 500 W

Type：Halogen

Luminous flux：4 × 9500 lm

Life：2000 h

Mains supply：Continuous

                        ER2500CX  generating set：13 h(after filled up)

                        EG6500CX generating set：12 h(after filled up)

Min. height：1800 mm

Max. height：3500 mm / 4500 mm / 5700 mm

Lifting time：30 s

Rated output voltage：220 V AC

Rated output power：2000 W( ER2500CX )

                                  5000 W( EG6500CX )

Rated capacity of fuel tank：15 L

Degree of protection：IP65

Ambient temperature：-20 ºC to +55 ºC

Light fittings：7.0 kg

Telescopic mast：8.0 kg

KD6500E generating set：95.0 kg

DIMENSION DRAWINGS

ACCESSORIES

ER2500CX  generating set：13 h(after filled up)

EG6500CX generating set：12 h(after filled up)
